GD32H75E

Overview
Product selector
Documentation

Overview

The GD32H75E is the product line that offers EtherCAT^® SubDevice Controller support within the GD32H7xx product series. Its main frequency is up to 600MHz, and it supports up to 3840K Flash and 1024K SARM. It also integrates various digital and analog peripheral resources, provides BGA240 package options. It is equipped with GDSCN832 series EtherCAT SubDevice Controller series supports QFN64 package. It can be widely used in various application scenarios such as servo motor control, variable frequency drive, industrial PLC, industrial communication module, etc.

● 2 Internal PHY port and 1 external MII

● 8x Fieldbus Memory Management Units (FMMUs)

● 8x Sync Manager Entities

● 8KB DPRAM

● Distributed clock 64-bit, support allows synchronization with other EtherCAT^® devices

● Support 8/16bit, serial/parallel synchronization, SPI/QSPI/OSPI slave device

● 1.8V to 3.3V variable voltage I/O

Product selector

Hide filter

Show filter

Reset

2 Results

Download to Excel

Part No	Core	Series	Package	Max Speed (MHz)	Flash (Bytes)	SRAM (Bytes)	I/O up to 116 up to 113	GPTM (32bit) ≥ ≤	GPTM (16bit) ≥ ≤	Advanced TM (16bit)	HRTM	Basic TM (64bit)	Basic TM (32bit)	Basic TM (16bit)	LPTM (32bit)	LPTM (16bit)	SysTick (64bit)	SysTick (24bit)	WDG	RTC	USART+UART	LPUART	I2C	QSPI	SPI	I2S	CAN 2.0B	USB 2.0	Ethernet ≥ ≤	EtherCAT Slave Controller	SDIO	MFCOM	LIN	LCD-TFT	Segment LCD	Camera	IPA	SAI	TMU	EXMC	CEC	14bit ADC Units (CHs) 2(22) 2(20)	12bit ADC Units (CHs)	12bit DAC Units	Comp	IEEE 802.11	Bluetooth
GD32H75EYMJ6	Cortex®-M7	GD32H75E	BGA240	600	3840K	1024K	up to 116	4	10	2	0	2	2	0	0	0	0	1	2	1	8	0	4	1	6	4	3xFD	FS+HS	2	1	0	0	0	0	0	0	0	0	1	1	0	2(22)	1(15)	1	2	0	0
GD32H75EYMJ6B	Cortex®-M7	GD32H75E	BGA240	600	3840K	1024K	up to 113	3	9	2	0	2	2	0	0	0	0	1	2	1	8	0	4	1	6	4	3xFD	FS+HS	0	1	0	0	0	0	0	0	0	0	1	1	0	2(20)	1(15)	1	2	0	0
